X, Y Two-axis coordinated positioning speed (MAX): 2.4 G
Positioning acceleration (MAX): <0.373 mrad
Positioning accuracy: ±0.05 mm/m
Re-positioning accuracy: ±0.02 mm
MMaximum load weight: 1962 lb (890 kg)
Laser resonator: Hans Photonics, IPG or Max Photonics
Laser head: PRECITEC (Germany Brand)
Controlling System: Beckhoff (Germany Brand)
X-Y-Z Servo Motors: X-2x9700W; Y- 1x6880W ; Z-1x940W
IPG-YLS Specification: YLS-6000
Laser Mode: CW,QCW
Wavelength: 1070-1080nm
Standard output laser power: 6000W
Laser beam quality: ≤4mm*mrad
Modulation speed: 5kHz
Delivery fiber core diameter: ≥50μm
Output stability: ±2%
Power supply: 400-460V/3P+PE@50-60Hz
PRECITEC new generation pro-cutter laser cutting head. Optimized cutting process, monitoring cutting conditions through "APP" use easily and friendly
Eagle Eye (CCD) technology, ultra fast positioning of the sheet metal edge, minimum cutting downtime, in addition it can also process punching parts and precut parts due to secondary positioning function.
Auto exchanging table with hydraulic lifting system
