Max Turning Diameter: 13.78"
Max Turning Length 15.75"
Swing Over Bed: 20.08"
X Axis Travel: 9.53"
Z Axis Travel: 17.32"
Spindle Speed: 45-4500 RPM
Spindle Bor/Spindle Bar: 2.99"/2.56"
Spindle Motor: 15/20HP
Spindle Nose: A2-6
Turret Capacity: 12 Stations
Turret Index Time: .5 Sec
Tailstock Taper: MT-4
Tailstock Quill Diameter: 2.95"
Tailstock Quill Travel:3.15"
Chuck Size: 10" Chuck
Dimensions: 105"x64"x69"
Weight: 8800 lbs
