Capacity: 55 US Tons
Ram Stroke: 5”
Open Height: 15.74”
Closed Height: 10.82”
Table Size: 15.74”x 15.74”
Throat Depth: 9.84”
Power: 5-HP Servo Motor
¶ Main drive High Torque Servo Motor with Controls
¶ User Friendly 7” Touch Screen Interface HMI
¶ Production Counters (Total, Batch)
¶ Mould Data Storage memory & Management System
¶ On Screen stroke adjustment of cylinder
¶ On Screen pressure & Tonnage setting
¶ Compact Hydraulic systems with Logic, conventional &
Servo valves
¶ Hydraulic Overload Protection
¶ Ram reversal with pressure sensing or limit sensing by selection
¶ Long lasting slide Guiding Arrangement
¶ Dual Check Safety Electrical Circuit
¶ Service Platform & Monkey ladder for easy accessibility
¶ Positive stopper for Ram holding
¶ IP 54 class electrical panel & closures
¶ Two-hand operator safety to ensure accident-free operation
