ENERGY MISSION PBE 5061 - PRESS BRAKES AVAILABLE UP TO 2,000 TONS
Have one to sell?
ConditionNew
New
Bending Force: 551 US Tons
Bending Length: 240"
Clear Pass: 208.66"
Open Daylight: 23.62"
Ram Stroke: 14.76"
Table Width: 8.66"
Table Height: 38.78"
Throat Depth: 21.65"
Power: 50HP
Approach: 2.95"/sec
Working Speed:.2"/sec
Return Speed: 3.15"/sec
Length: 252"
Width:98"
Height: 177"
X-Axis: 23.62"
R Axis: 7.87"
Weight: 99,225 lbs
• Press Beam Depth Accuracy: ± 0.01mm
• Press Beam Depth Repeatability: ± 0.01mm
• Back Gauge Accuracy: ± 0.1mm
• Back Gauge Repeatability: ± 0.1mm
• 3 Axis machine with automatic, accurate & fast back gauge
• CybTouch 8PS Controller from CYBELEC Switzerland
• Rigid upper beam guide on 12-point roller bearings
• Ultrasonically & tensile tested IS:2062 grade steel structure ensures the rigidity & avoid deflection.
• The frame is machined on Floor Boring Machine ensuring single reference accurate machining.
• Quick release clamps
• Back gauge assembly included ball screw, AC Servo drive, LM guides & timer belt
• Back gauge fingers mounted on LM guide
• Quick ‘V’ groove change over with self-centred die with rail.
• Hardened & grounded 2‘V’ / 4‘V’ die & semi gooseneck punch
• Front sliding sheet support with LM guides for easy movement
