Top-Shaft Diameter : Ø 60 mm
Bottom-Shafts Diameter : Ø 50 mm
Rolls Diameters : Ø 180 mm
Working Speed : 5 m/min
Motor Power : 3 kW
Weight : 1.000 kg
Dimensions : 1200 x 850 x 1200 (L x W x H)
Power Supply : 380V-3Ph-50Hz or on request
Steel Construction Frame
3 Rolls are Powered
Horizontal and Vertical Working Position
Mobile Control Panel
Hardened Standard Rolls
Hardened and Grounded Shafts
Digital Read-outs (2 pcs)
3 – axis Mechanical Lateral Angle Guide Rolls
Centralised Lubrication system
Hydraulic elements : Duplomatic (Italian) components used.
Electric equipment : Siemens (German) or Telemecanique (France)
Built according to EC Safety Directives .(CE Mark) and ISO 9000 Certificate
User’s Manual in English
