2006 KRRAS RAS 306
Have one to sell?
ConditionUsed
1 available
The 2006 KRRAS RAS 306 is a robust, 120" wide hydraulic shear capable of cutting up to ¼" mild steel in 10' lengths, with variable rake, quick blade gap, and advanced back gauge and sheet support features for precision and efficiency.
Core Cutting Capacity
• Max thickness: 0.25" mild steel
• Cutting length: 10'
• Cutting angle: Variable 1°–3°
• Blade type: Four-sided high-carbon, high-chrome D2 quality
Machine Dimensions & Weight
• Overall dimensions (L×W×H): ~148" × 70" × 85" (3750 × 1770 × 2150 mm)
• Weight: ~5.5 tons (12,500 lbs)
Operational Specs
• Backgauge range: 31" (787 mm) standard; up to 39" (990 mm) with motorized front-operated backgauge
• Strokes per minute (SPM): 11–17
• Motor power: 7.5 kW (10 hp)
• Table height: ~34.5" (876 mm)
Features & Accessories
• Variable rake angle adjustment (1°–3°)
• Rapid blade gap adjustment
• Independent hydraulic hold-down clamping
• Front-operated motorized backgauge with digital readout
• Shadow line lighting & finger guard for clear cut visibility
PGP-401 NC positioner (Touch-and-Go, stroke counter, auto-retraction)
Notable Notes
• The RAS 306 is designed for heavy-duty trimming of 10' sheets, with built-in safety valves and overload protection.
• Standard configuration includes a 39" side squaring arm with disappearing stops
The 2006 KRRAS RAS 306 is a robust, 120" wide hydraulic shear capable of cutting up to ¼" mild steel in 10' lengths, with variable rake, quick blade gap, and advanced back gauge and sheet support features for precision and efficiency.
Core Cutting Capacity
• Max thickness: 0.25" mild steel
• Cutting length: 10'
• Cutting angle: Variable 1°–3°
• Blade type: Four-sided high-carbon, high-chrome D2 quality
Machine Dimensions & Weight
• Overall dimensions (L×W×H): ~148" × 70" × 85" (3750 × 1770 × 2150 mm)
• Weight: ~5.5 tons (12,500 lbs)
Operational Specs
• Backgauge range: 31" (787 mm) standard; up to 39" (990 mm) with motorized front-operated backgauge
• Strokes per minute (SPM): 11–17
• Motor power: 7.5 kW (10 hp)
• Table height: ~34.5" (876 mm)
Features & Accessories
• Variable rake angle adjustment (1°–3°)
• Rapid blade gap adjustment
• Independent hydraulic hold-down clamping
• Front-operated motorized backgauge with digital readout
• Shadow line lighting & finger guard for clear cut visibility
PGP-401 NC positioner (Touch-and-Go, stroke counter, auto-retraction)
Notable Notes
• The RAS 306 is designed for heavy-duty trimming of 10' sheets, with built-in safety valves and overload protection.
• Standard configuration includes a 39" side squaring arm with disappearing stops
