EM CNC PBE 830

Description

• Model : EM CNC PBE 830
• Capacity : 80 MT.
• Bending Capacity in M.S. : 3mm X 3100mm.
• Table size : 90mm X 3100mm.
• Table Height : 850mm.
• Clear Pass : 2550mm.
• Ram Strokes. : 200mm.
• Open Height : 385mm.
• Close Height : 185mm.
• Throat Depth : 250mm.
• X- Axis Travel : 600mm
• Ram Speed mm/sec. :
- Approach : 100mm/sec.
- Pressing : 7mm/sec.
- Return : 80mm/sec.
• Motor : 7.5H.P.
• Over all Dimension :
- Length : 3800mm.
- Width : 2000mm.
- Height : 2850mm.
• Oil Tank capacity : 180 Liters.
• Oil Specification : 68 grade Hyd. Oil
(HP, Castrol, IBP, Servo or any equivalent reputed make)
• Main Drive Motors.
• Front cylinder design.
• Selection of Auto, Inch & Single Cycle Auto thru screen.
• Servo Hydraulics from HAWE (Hoerbiger – Germany) for Y1-Y2 Axis control.
• Linear guided type Press brake scale for Y1 - Y2 axis position measurement.
• AC servo drive for X axis control.
• Back gauge assembly included ball screw, drive unit, rotary encoder & LM guides.
• Sliding sheet support (2 Nos) mounted on L.M. guides.
• Pair of foot switch
STANDARD CYBELEC CYB TOUCH 12PS CONTROLLER FROM SWITZERLAND SR NO.1
• 12" color graphic CRT screen, 800x600 pixels with LED backlight control.
• 2D graphic part
• Automatic Bend sequencing.
• Memory capacity
§ 100 Punches
§ 100 Dies
§ 300 Programs
§ 24 Sequences per program
• Bend allowance calculation.
• Pressure – crowning calculation.
• Modulable tools for each part or bend.
• Punch depth calculation.
• Angle and back gauge correction.
